BluGuitar AMP1 Nanotube 100 Guitar Amplifier Overview:

AMP1 delivers a wide tonal palette, from jazz to metal, in professional quality. Thomas’s dream was to put the immense power and character of vintage tube amplifiers into one small package that would fit into any glove compartment or gigbag – without compromising on the tones. Mission accomplished!

VERSATILE AND LOUD
AMP1 is designed for professional use onstage and in the studio. The NANOTUBE 100-watt power amp delivers your own tonal palette with the best tube quality and enormous sound pressure levels.

Four amazing, modifiable channels will take you on a stunning journey through the history of guitar amplification (from Clean to Vintage to Classic and Modern tones), and AMP1 also features switchable and adjustable Boost and Reverb controls, three integrated footswitches, a truly outstanding Speaker Simulation output for recording, and a headphone output, giving you all the options you would expect from a modern, boutique tube amp.

FLEXIBLE
You can take your AMP1 with you wherever you are – it fits right in your gigbag. It’s incredibly compact and very light. Just to make everything that little bit quicker before and after the gig, AMP1 can be securely attached to (and then removed from) a single handle on your pedalboard or amp cab thanks to EASYLOCK – the magnetic attachment system from BluGuitar®. With the REMOTE1 floor control, you can build AMP1 into a fully programmable amp system – including adjustable PowerSoak, MASTER, VOLUME (CLEAN CHANNEL), GAIN (OVERDRIVE CHANNELS) and MIDI functions. AMP1 offers you the ultimate in practicality and tonal flexibility.

INDIVIDUAL
AMP1 will make you stand out from the crowd. It offers you every possibility to find your own personal tone without having to get lost in a jungle of countless functions.

If you’re a player who needs just two basic sounds, then AMP1 is your perfect match. Should you want more sounds to play with, though, REMOTE1 offers a bunch of extra possibilities. Plus, if you want to integrate your favourite pedals into your AMP1 setup, use the REMOTE1 with the LOOPERKIT to create a fully programmable switching system featuring four true bypass relay loops.

YOUR TONE
Only with ‘your tone’ you will become one with your guitar. Find it, and you’ll be truly happy. You’ll find that it’s not just AMP1’s tones that inspire you, but that its playing feel will also draw you in – until you’re hooked! AMP1’s direct response, fat bass that never muddies, trebles that never get tinny and annoying, and almost unfathomable depth of tone allow you to become one with your guitar. With AMP1 and its Custom Controls you have everything you need to find your own tone!

Features:
Four channels: ONE Clean Channel and THREE discreed Overdrive Channels.
NANOTUBE: The Nanotube works in the output stage that gives AMP1 100 Watts of character, punch, and the assertiveness of a large 100-watt tube amp.
BOOST: Boosts AMP1’s channels. The character is from transparent to creamy, with adjustable “intrinsic distortion”.
CUSTOM CONTROL: All channels (except Vintage) feature adjustable sound filters with which you can tune their tonal character individually. There’s also a volume controller for each channel.
REVERB: AMP1’s digital reverb is modelled on a classic spring reverb.
NOISE GATE: Choose between SOFT, OFF or METAL modes.
LOOP: The Effects Loop can be used in serial or parallel mode. The FX Loop Level can also be switched for stompboxes or studio effects.
REC OUT: You can connect to headphones or a mixing desk with this multifunctional port. An elaborate filter circuit simulates the authentic sounds of a genuine guitar amp cabinet.
PHONESIt’s possible to use AMP1 just with headphones. Just don’t connect to a speaker.
SILENT RECORDING: Direct recording without speakers.
AC 100-240V: A modern switch-mode power supply constantly delivers the required operating voltage, regardless of network voltage.

EXPANDABLE
FOOT CONTROLLER: REMOTE1 is designed to be a convenient foot controller for AMP1.
2ND MASTER: A second Master Volume is available through REMOTE1. This is activated by footswitch and controls a range of 10dB.
PROGRAMMABLE: In connection with REMOTE1 or MIDI1 you can control VOLUME (CLEAN CHANNEL) and GAIN (OVERDRIVE CHANNELS) and save it for each preset separately.
POWER SOAK: AMP1’s PowerSoak works in a completely new and neutral-sounding way, without any power resistors that produce a lot of heat.
MIDI: AMP1 can be controled with other MIDI controllers using the MIDI1 adapter interface.
EASYLOCK: To attach AMP1 magnetically to a pedalboard or cabinet.

Specifications:
Input: unbalanced jack
Sensitivity: OV-15V P2P maximum
Input impedance: 2 M Ω
Power output: about 100 watts

Speaker connections
Input jacks: 1 x 8 Ω, 1 x 16 Ω

FX Send/Return: unbalanced jack

FX Send-Output and FX-Return Input levels dependent on switching
LOW: -10dBU +/-1dB or 0.7V P2P
HI: +4dBU +/-1dB or 3.46V P2P
FX Send-Output impedance: < 1.3kΩ
FX Return-Input impedance: > 18kΩ

Mains voltage range: 100-240V +/- 10 % 50-60 Hz
Power consumption: max. 150 watts
Fuses: internal: 3.15 SB

Ambient operating temperature range:
0 °C to + 35 °C

Logic MIDI control system:
STM 8 S

System interfaces:
Upgradeable with external programming device
BluGuitar® specific, asynchronous data protocol.

Dimensions:
Width: 245 mm (9.65")
Height: 68 mm (2.68")
Depth: 192 mm (7.56")

Weight: 1.2 kg
