DV Mark EVO 1 Guitar Amplifire Overview:

DV Mark keeps creating tools revolutionizing the classics to present days, in a word ... EVOLUTION!

We know there are many amps that have cool tones, but one of the biggest problem in the sea of choices is they deliver their tone in one unique way, and it is not always the 'right' sound for each unique performance.

NOW the ideal amp does exist... the DV MARK EVO 1.

Thanks to six AMPS tone choices for each channel many cool options come with this rEVOlutionary amp, plus you can update them with other preferred amps you can download from our website.

The DV MARK EVO 1 features two channels with a classic standard amp controls interface, reverb control for each, MIDI IN, on board tuner, aux in and headphones out, FX loops, XLR Line Out, Boost, and a powerful 250W MPT (Mark Proprietary Technology) power amp with an impressive warm tone and incredible dynamic.

Features:

EVO 1 Software

You can update AMPs choices on each channel at your preference thanks to the DV MARK EVO 1 SOFTWARE, that also allows to update Reverb type choices for each channel and customize their parameters, plus you can choose preferred CAB/Speaker Emulator to be assigned to the XLR Line Out.

EVO 1 Controller

The optional DV Mark EVO 1 CONTROLLER allows to switch between CH1 and CH2, turn on/off the REV1, REV2 and BOOST, plus accessing the TUNER with MUTE function pressing and holding the boost switch. The EVO 1 can be controlled also via programmable MIDI pedalboard.

MW Amp Bag Large

The optional MW Amp Bag Large allows you to trasport your DV Mark EVO 1 head in a knapsack along with cables, charts, etc. Ultra-handy for in-town gear transport.

 Specifications:

INPUTS

INPUT 1 (passive): impedance 1MΩ
INPUT 2 (active): impedance 1MΩ
AUX IN: stereo mini-jack 3.5mm
RETURN 1 / RETURN 2: mono jack 1/4"
USB: type B
MIDI: DIN 5 poles

OUTPUTS

SPEAKER OUTPUT (4ohms minimum load)
two mono jack 1/4" + one Speakon (in parallel)
PHONES : stereo mini-jack 3.5mm
SEND 1 / SEND 2: mono jack 1/4"
XLR LINE OUT
CAB/Speaker Emulator is assignable to this output using the DV Mark EVO 1 software.

CHANNELS
TWO (with six Virtual AMPs per channel)

EQUALIZATION (per channel)
LOW-MID-HIGH

CONTROLS
GAIN (per channel)
AMPS Selection: 6 for CH1 / 6 for CH2
LEVEL (per channel)
REV 1
REV 2
MASTER
PHONE LEVEL
BOOST

MIDI FUNCTIONS
Switch CH1, CH2
FX1 ON/OFF, FX2 ON/OFF
BOOSTER ON/OFF
MUTE/TUNER
Controllable by the optional EVO1 Controller / MIDI Pedalboard

OTHER FEATURES
Channels Switch
+4dB / -10dB and GND Lift switches (LINE OUT)
TUNER (with MUTE function)
440Hz / half step down / whole step down modes

DIMENSIONS
14.18”/ 36 cm (w); 3.94”/ 10 cm (h); 10”/ 25.4 cm(d)

WEIGHT
7.05 lbs / 3.2 Kg

OUTPUT POWER (MPT Power Amp)
250W RMS @ 4 ohms, 150W RMS @ 8 ohms

POWER REQUIREMENT
100/120V; 230V; 240V
50/60Hz

Made in Italy
