EVH Wolfgang Special QM 6 String Electric Guitar Overview:

Road-tested in arenas around the world, the Wolfgang Special is a purebred music-making machine, designed with stunning style, giant sound and high-speed playability.

The Wolfgang Special QM features a basswood body with an arched quilt maple top and a robust graphite-reinforced bolt-on quartersawn baked maple neck. The neck is carved and rolled to Eddie Van Halen's exacting specifications and features a hand-rubbed satin urethane finish on the back. Primed for high performance, energetic riffing and blazing leads, the 12"-16" compound radius baked maple fingerboard has 22 jumbo frets and black dot inlays. Truss rod adjustments have also never been easier thanks to a spoke wheel conveniently located at the base of the neck.

A pair of flagship custom-designed EVH Wolfgang Alnico 2 humbucking pickups are mounted directly to the body, providing dynamic yet articulate voicing, as well as endless sustain for powerful chords and melody lines. A sturdy and dependable EVH-branded Floyd Rose locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna retunes to drop-D and back with strict accuracy at the flick of a finger. The volume knob with treble bleed circuit has a 500K EVH Bourns low friction pot for smooth swells and a tone control knob with a 250K Bourns high friction tone pot that prevents accidental tone shifting.

Features

• 25.5" scale length

• Basswood body with arched quilt maple top

• Graphite-reinforced bolt-on quartersawn baked maple neck

• Neck is carved and rolled to Eddie Van Halen's specifications with a hand-rubbed satin urethane finish on the back

• 12"-16" compound radius baked maple fingerboard with 22 jumbo frets and black dot inlays

• Convenient heel-mount truss rod adjustment spoke wheel

• Direct mount EVH Wolfgang Alnico 2 bridge and neck humbucking pickups

• EVH-branded Floyd Rose locking trem and R2 locking nut

• EVH D-Tuna

• Three-way toggle switch, EVH volume control (500K EVH Bourns Low Friction Pot) with treble bleed circuit and tone control (250K EVH Bourns High Friction Pot)

• Available in Solar with cream body binding and chrome hardware



Specifications:

Body

• Body: Basswood

• Body Finish: Gloss Urethane

• Body Shape: Wolfgang

• Body Top: Arched Quilt Maple

• Body Binding: 1-Ply Cream

• Body Material: Basswood

Neck

• Headstock: EVH Wolfgang

• Neck Material: Quartersawn Baked Maple

• Neck Finish: Hand-Rubbed Satin Urethane

• Neck Shape: Wolfgang Backshape

• Neck Construction: Bolt-On with Graphite Reinforcement

• Neck Thickness.: 805" at 3rd & .890" at 12th Fret

• Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)

• Fingerboard Material: Baked Maple

• Position Inlays: Black Dot

• Side Dots: Black

• Number of Frets: 22

• Truss Rod Nut: Heel-Mount Truss Rod Adjustment Wheel

• String Nut: Floyd Rose R2 Locking

• Nut Width: 1.625" (41.3 mm)

• Nut Material: Floyd Rose R2 Locking

Hardware

• Bridge: EVH-Branded Floyd Rose Locking Tremolo with EVH D-Tuna

• Tremolo Block: Brass

• Pickup Covers: Black

• Control Knobs: Black Plastic with White Indicator

• Switch Tip: Black

• Hardware Finish: Chrome

• Tuning Machines: EVH-Branded Gotoh

• String Trees: Floyd Rose Retainer Bar

• Strings: EVH Nickel Plated Steel (.009-.042 Gauges)

• Tremolo Arm: Floyd Rose 1000 Series Locking

• Strap Buttons: Oversized

Electronics

• Bridge Pickup: Direct Mount EVH Wolfgang Humbucking

• Neck Pickup: Direct Mount EVH Wolfgang Humbucking

• Pickup Configuration: HH

• Controls: Volume (500K EVH Bourns Low Friction Pot) with Treble Bleed Circuit,  Tone (250K EVH Bourns High Friction Pot)

• Switching: 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup

Measurements

• Dimensions: 4.50x15.20x42.10 IN

• Shipping Weight: 11.45 LB

• Fret Size: Jumbo

• Scale Length: 25.5" (64.77 cm)

• Shipping Length: 42.10 IN

• Shipping Height: 4.50 IN

• Shipping Width: 15.20 IN
