Ibanez RG8EX 8 String Electric Guitar Overview:

Ibanez builds guitars for players of all levels—from beginners to the most demanding masters of the instrument. Regardless of price, Ibanez always strives to offer the absolute best sound, style, and playability in its class. The Standard series incorporates all the staples the Ibanez brand is famous for, such as fast necks, floating trems, and high-octane distortion in a package that is available and accessible to most players.

Features:



Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end











Mono-unit output jack
The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.





F108 bridge
The F108 bridge enriches sustain. String height adjustment can be done easily and independently.









IBZ-8 pickups
IBZ-8 pickups are designed for extended range guitars and deliver a tight low end that handle high-gain settings without losing tonal clarity.









Wizard II 5pc Maple/Walnut neck
Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.







Specifications:

• neck type: Wizard II-85pc Maple/Walnut neck

• top/back/body: Meranti body

• fretboard: Jatoba fretboardWhite dot inlay

• fret: Jumbo frets

• number of frets: 24

• bridge: F108 bridge

• string space: 10.5mm

• neck pickup: IBZ-8 (H) neck pickupPassive/Ceramic

• bridge pickup: IBZ-8 (H) bridge pickupPassive/Ceramic

• factory tuning: 1D#,2A#,3F#,4C#,5G#,6D#,7A#,8F

• strings: D'Addario EXL120-8

• string gauge: .009/.011/.016/.024/.032/.042/.054/.065

• hardware color: Black

NECK DIMENSIONS

• Scale : 686mm/27"

• a : Width: 55mm at NUT

• b : Width: 80mm at 24F

• c : Thickness: 20mm at 1F

• d : Thickness: 21.5mm at 12F

• Radius : 400mmR
