Studiomaster Insta SUB8A 8inch Ceiling Flown Active Subwoofer
Studiomaster Insta SUB8A 8inch Ceiling Flown Active Subwoofer Overview:
The INSTA SUB8A is an ultra-compact 8 "active subwoofer consisting of a Φ38 8" LF unit. It can be fixed or hidden under furniture for placement; Built in high-efficiency 3-way 400W/4Ω "Class-D" power amplifier, 1 ultra-low way can be connected in parallel with a passive subwoofer Insta.
- Type - 8 "active sub
- Frequency response(-10dB) - 45Hz - 120Hz
- Rated Power - 200W (RMS) / 800W (peak)
- Nominal impedance - 8 ohm
- Max SPL (@1m) - 114dB (peak)
- Coverage (H × V) - 80° × 80°
- LF Transducer - 8” / ď38mm voice coil /
- 200W Ferrite magnet
- Sensitivity(1m@1W) - 85dB
- Connectors - 2 × Binding posts
- Dimensions (W × H × D) - 515 × 200 × 425mm
(including bracket)
- Net weight - 17kg
Original: $68,400.00
-70%$68,400.00
$20,520.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Studiomaster Insta SUB8A 8inch Ceiling Flown Active Subwoofer Overview:
The INSTA SUB8A is an ultra-compact 8 "active subwoofer consisting of a Φ38 8" LF unit. It can be fixed or hidden under furniture for placement; Built in high-efficiency 3-way 400W/4Ω "Class-D" power amplifier, 1 ultra-low way can be connected in parallel with a passive subwoofer Insta.
- Type - 8 "active sub
- Frequency response(-10dB) - 45Hz - 120Hz
- Rated Power - 200W (RMS) / 800W (peak)
- Nominal impedance - 8 ohm
- Max SPL (@1m) - 114dB (peak)
- Coverage (H × V) - 80° × 80°
- LF Transducer - 8” / ď38mm voice coil /
- 200W Ferrite magnet
- Sensitivity(1m@1W) - 85dB
- Connectors - 2 × Binding posts
- Dimensions (W × H × D) - 515 × 200 × 425mm
(including bracket)
- Net weight - 17kg
